1200w Mini Laser Welding Machine Portable Handheld Laser Welding Machine AC220V

Name: 1200w Mini Laser Welding Machine Portable Handheld Laser Welding Machine AC220V
Brand: Temei
Price: 4000 USD

Quality 1200w Mini Laser Welding Machine Portable Handheld Laser Welding Machine AC220V for sale

Brand Name : Temei

Model Number : TM-40D

Place of Origin : china shenzhen

MOQ : 1

Price : 4000usd

Payment Terms : T/T

Supply Ability : 1,000 units per month

Delivery Time : 3~7day

Packaging Details : wooden box

Name : Portable Handheld Laser Welding Machine

Model : TM-40D

Work mode : Continuous mode / Pulse mode

Laser source : Fiber laser (GW)

Laser power : 1200W

Output laser wavelength : 1080±10

Maximum modulation frequency : 10kHz

Laser response time : <30us

Swing mode : Single pendulum

Swing amplitude : 0~5mm

Laser incidence mode : Coaxial

Protection mirror specifications : D20mm,T3mm

Operating temperature range : -10~40°

Humidity range : ≤95 degree

Input voltage : AC 220V 50Hz/60Hz

Mirror specifications : 23.3 × 16mm2 ,T2mm

Focus lens specification : D20mm,F150mm

Collimating mirror specification : D12.7mm,F50mm

Cooling method : Air-cooled

Dimensions : 250 x 579 x 479 mm (L ×W × H)

Application Materials : Carbon steel,Galvanized steel,Aluminum alloy,Brass etc.

Contact Now

Configuration and Parameters

Name	Portable Handheld Laser Welding Machine
Model	TM-40D
Work mode	Continuous mode / Pulse mode
Laser source	Fiber laser (GW)
Laser power	1200W
Output laser wavelength	1080±10
Maximum modulation frequency	10kHz
Laser response time	<30us
Swing mode	Single pendulum
Swing amplitude	0~5mm
Laser incidence mode	Coaxial
Protection mirror specifications	D20mm,T3mm
Supporting fiber optic cable length	5±0.5m
Operating temperature range	-10~40°
Humidity range	≤95 degree
Input voltage	AC 220V 50Hz/60Hz
Mirror specifications	23.3 × 16mm2 ,T2mm
Focus lens specification	D20mm,F150mm
Collimating mirror specification	D12.7mm,F50mm
Shielding gas	Inert gas
Maintain the range of air pressure	0.1~1.0 MPa
Cooling method	Air-cooled
Dimensions	250 x 579 x 479 mm (L ×W × H)
Net Weight	26kgs
Application Materials	Carbon steel,Galvanized steel,Aluminum alloy,Brass etc.

FAQ

Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available across the world. We need your machines running in order to keep your business running.

Q: I am not sure if this machine suitable for my work?
A: Don't worry, just tell me your working materials, max working area and cutting thickness,then I will recommend you the most suitable machine for you.

Q: Are you factory or trading company?
A: We are factory, which manufactures CNC cutting machines , with 10 years experience in CNC machine's industry.

Q:How can i do if the machine goes wrong?
A:If confronted with such problems,online service is offered,you could contact our sales.Also,we offer engineer delivery
service.Please contact us asap and don't try fix the machine by yourself or someone else.We will response within 12 hours as quick as we can to solve it for you.
